1169940000 - RoHS Compliant Sensor/Actuator Connector with Plug-in Enclosure

1169940000 - RoHS Compliant Sensor/Actuator Connector with Plug-in Enclosure

SKU: SKU: 1169940000 Download PDF

Variant:
  • 1169940000 - RoHS Compliant Sensor/Actuator Connector with Plug-in Enclosure
Regular price Now $9.62
Regular price BEFORE   $0.00 Sale price Now $9.62
Sold out
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Discover the versatility of this sensor/actuator plug-in connector, which includes integrated plugs and an unfilled enclosure This product meets RoHS standards and is certified with UL certificate number E344862, ensuring compliance with exemption 6c under RoHS regulations Ideal for reliable performance, it combines functionality with safety.

Features and Benefits:

    •Net weight is 21.12 grams.

    •Housing material is made of copper-zinc alloy.

    •Protection degree is IP67 and IP69K.

    •Temperature range for housing is between -40 to +125 °C.

    •Shield connection available.

    •Pollution severity rated at level 3.

Specifications:

 UL File Number E344862
 RoHS Compliance Status Compliant with exemption
 RoHS Exemption 6c
 REACH SVHC Lead 7439-92-1
 SCIP ebf89fc8-a87f-4691-b87a-dfb9921774b4
 ETIM Classifications {'ETIM 6.0': 'EC000437', 'ETIM 7.0': 'EC003556', 'ETIM 8.0': 'EC003556', 'ETIM 9.0': 'EC003556', 'ETIM 10.0': 'EC003556', 'ECLASS 9.1': '27-44-02-02', 'ECLASS 10.0': '27-44-02-24', 'ECLASS 11.0': '27-44-02-24', 'ECLASS 12.0': '27-44-02-24', 'ECLASS 13.0': '27-44-02-24', 'ECLASS 14.0': '27-44-02-24', 'ECLASS 15.0': '27-44-02-24'}
