1112940000 - 33.3mm White WAD 8 Marker for Group Use (Pack of 48)

1112940000 - 33.3mm White WAD 8 Marker for Group Use (Pack of 48)

SKU: SKU: 1112940000 Download PDF

Variant:
  • 1112940000 - 33.3mm White WAD 8 Marker for Group Use (Pack of 48)
Regular price Now $19.07
Regular price BEFORE   $0.00 Sale price Now $19.07
Sold out
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the WAD 8 MC NE WS marker, expertly crafted for compatibility with group markers and covers This high-performance marker boasts dimensions of 333 x 8 mm and is designed with an 800 mm pitch Manufactured from polyamide 66, it meets RoHS standards, ensuring environmental safety With its neutral printing style and clean white hue, this marker is versatile and suitable for a wide range of applications.

Features and Benefits:

    •Compliant with RoHS without exemptions.

    •Operating temperature ranges from -40 to 100 °C.

    •Contains no SVHC above 0.1 wt%.

    •Flammability rating of V-2.

    •Compatible with WDU 4, WEW 35/2, and ZEW 35/2 assemblies.

Specifications:

 Depth 11.74 mm
 Height 33.3 mm
 Width 8 mm
 Net weight 1.331 g
 Operating temperature range -40...100 °C
 Basic material Polyamide 66
 Number of markers per combination 1 MultiCard = Cover
 Number of markers per packaging unit MultiCard
 Type of printing neutral
 Pitch in mm (P) 8 mm
 ETIM 6.0 EC002848
 ETIM 7.0 EC002848
 ETIM 8.0 EC002848
 ETIM 9.0 EC002848
 ETIM 10.0 EC002848
 ECLASS 9.0 27-14-11-92
 ECLASS 9.1 27-14-11-92
 ECLASS 10.0 27-14-11-92
 ECLASS 11.0 27-14-11-92
 ECLASS 12.0 27-14-11-92
 ECLASS 13.0 27-25-03-90
 ECLASS 14.0 27-25-03-90
 ECLASS 15.0 27-25-03-90
