2443150700 - M8 Sensor/Actuator Line, 4 Poles, 7m Shielded Cable

2443150700 - M8 Sensor/Actuator Line, 4 Poles, 7m Shielded Cable

SKU: SKU: 2443150700   Download PDF

Select a Variant:
  • 2443150700 - M8 Sensor/Actuator Line, 4 Poles, 7m Shielded Cable
Qty:
Regular price Now $49.78   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $49.78 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing this robust M8 sensor/actuator line, specifically designed with 4 poles and a generous cable length of 7 meters Equipped with a 90° socket, this shielded product guarantees consistent and dependable operation Made from halogen-free PUR sheath material, it prioritizes safety and compliance This unit adheres to RoHS standards with an exemption and carries certification under UL File Number E307231, ensuring quality and reliability for your projects.

Features and Benefits:

    •Shielded configuration.

    •Flexible installation with 90° connections.

    •Robust outer cladding material.

    •Compliant with RoHS and REACH standards.

Specifications:

 Cable length 7 m
 Number of poles 4
 Outer diameter 5.1 mm ± 0.2 mm
 Sheath material PUR
 Temperature range, moving -25...80 °C
 Nominal current 4 A
 Nominal voltage 30 V
 Insulation resistance 10^8 Ω
 Protection degree IP65, IP66, IP67, IP68 when screwed in
 Bending cycles 2 Mio
 Acceleration 5 m/s²
 Speed 100 m/s
 Codings A-coded
 Plugging cycles ≥ 100
