2050151000 - 10m Halogen-Free M12 Power Cable, 3 Poles Connection

2050151000 - 10m Halogen-Free M12 Power Cable, 3 Poles Connection

SKU: SKU: 2050151000

Select a Variant:
  • 2050151000 - 10m Halogen-Free M12 Power Cable, 3 Poles Connection
Qty:
Regular price Now $71.39   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $71.39 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing a versatile 10-meter power cable equipped with M12 connectors on both ends Featuring 3 poles, this cable includes 2 functional poles alongside a protective earth (PE) connection Made from an unshielded PUR sheath, it is halogen-free for safer use Please note, this cable is designed without an LED indicator, making it straightforward and efficient for all your connectivity needs.

Features and Benefits:

    •Compliant with RoHS regulations.

    •Length of 10 meters.

    •Not configurably adjustable in length.

    •3 poles designed for safety and reliability.

    •Outer diameter measures 8.5 mm ± 0.3 mm.

    •S-coded connection for secure fitting.

    •IP67 rated protection when connections are secured.

Specifications:

 Acceleration 5 m/s²
 Bending cycles 10 Mio
 Bending radius (moving) 7.5 x cable diameter
 Bending radius (stationary) 4 x cable diameter
 Core cross-section 1.5 mm²
 Temperature range (moving) -40...80 °C
 Temperature range (stationary) -50...80 °C
 Nominal current 12 A
 Nominal voltage 600 V
 Housing main material PUR
 Length 10 m
 Resistance to welding beads No
 Sheath material PUR
 Protection degree IP67
 Contact surface Gold-plated
