1867410150 - 1.5m Shielded Sensor/Actuator Line with 3 Poles

1867410150 - 1.5m Shielded Sensor/Actuator Line with 3 Poles

SKU: SKU: 1867410150

Variant:
  • 1867410150 - 1.5m Shielded Sensor/Actuator Line with 3 Poles
Regular price Now $20.44
Regular price BEFORE   $0.00 Sale price Now $20.44
Sold out
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Enhance your connectivity with this 15-meter sensor/actuator line, featuring a conveniently designed female socket at one end Built for resilience, it includes three poles and is crafted from high-quality PUR sheath material, providing effective shielding Although it does not come with an LED option, this component is ROHS compliant (with an exemption) and is certified under E307231 Its robust design caters to various bending requirements, ensuring reliable performance in demanding environments.

Features and Benefits:

    •M12 connection thread.

    •Gold-plated contact surface.

    •Suitable for cable carriers.

    •High resistance to oils and flame spread.

    •Meets IP65 to IP68 protection degrees.

Specifications:

 Cable length 1.5 m
 Number of poles 3
 Core cross-section 0.34 mm²
 Outside diameter 5 mm ± 0.2 mm
 Temperature range, moving -25...80 °C
 Temperature range, stationary -40...80 °C
 Nominal current 4 A
 Nominal voltage 250 V
 Insulation resistance 10^8 Ω
 Protection degree IP65, IP66, IP67, IP68
 Weight 59.84 g
 Sheath material PUR
