1865870500 - 5m Halogen-Free M12 Female Socket Sensor Actuator Cable, 8 Poles

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing a versatile cable from our sensor/actuator collection, designed with a female socket at one end without a connector This 5-meter long cable features 8 poles and is crafted from halogen-free PUR sheath material, ensuring safety and compliance Note that this cable does not include shielding or an LED, making it a straightforward solution for various applications.

Features and Benefits:

•Cable length of 5 meters.

•No configurable cable length.

•Core cross-section of 0.25 mm².

•Number of poles: 8.

•Outer diameter of 5.9 mm ± 0.2 mm.

•Shielded: No.

•Temperature range for moving: -25 to 80 °C.

•Temperature range for stationary: -40 to 80 °C.

•Suitable for cable carriers.

•Nominal current of 2 A.

•Nominal voltage of 30 V.

•Protection degree: IP67, IP65 when screwed in, IP66.

Specifications:
