1224010000 - 6 Pole RoHS Certified SAI-M23 Connector with Gold-Plated Contacts

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the SAI-M23-BE-6-F sensor/actuator plug-in connector, an essential component for your electronic projects This connector is RoHS compliant and boasts UL certification (file number E344862), ensuring it meets high safety standards Weighing only 862 grams, it features a female contact made from a durable copper-zinc alloy, enhanced with gold plating for superior conductivity Constructed from high-quality thermoplastic polyamide PA 6 and PBT, this connector is built to last with the capability of enduring over 1000 plugging cycles.

It supports a nominal current of 20 A and a nominal voltage of 300 V across its six poles, making it a reliable choice for various applications The connection type consists of solder cups, and the component carries a pollution severity rating of 3 Experience dependable performance with this advanced connector.

Features and Benefits:

•RoHS compliant.

•UL certified.

•Female gender contact.

•Gold-plated contact surface.

•Robust thermoplastic polyamide PA 6 and PBT housing.

Specifications:
