1078720000 - 0.5m M8 Thread Plug Connector with 4 Poles

1078720000 - 0.5m M8 Thread Plug Connector with 4 Poles

SKU: SKU: 1078720000 Download PDF

Variant:
  • 1078720000 - 0.5m M8 Thread Plug Connector with 4 Poles
Regular price Now $9.62
Regular price BEFORE   $0.00 Sale price Now $9.62
Sold out
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Enhance your projects with this versatile product, featuring integrated plugs and an M8 thread for a reliable connection Designed with a straight pin configuration, it offers a cable length of 05 meters and includes a total of four poles Compliant with RoHS standards, this item is ideal for a range of applications, ensuring safety and functionality.

Features and Benefits:

    •Gold-plated contact surface.

    •M8 connection.

    •IP67 protection degree when screwed in.

    •Temperature range of housing is -30 to +90 °C.

    •Plugging cycles of at least 100.

Specifications:

 Number of poles 4
 Strand / cable length 0.5 m
 Nominal current 4 A
 Nominal voltage 30 V
 Core cross-section 0.25 mm²
 Cable gland M8
 Contact surface Gold-plated
 Housing main material Brass, nickel-plated
 Rated voltage 60 V (3-pole) / 30 V (4-pole)
 Temperature range of housing -30…+90 °C
 Coding none
