ZAC50EN02 - 4-Port Industrial Ethernet Switch with PoE Capability

ZAC50EN02 - 4-Port Industrial Ethernet Switch with PoE Capability

SKU: ZAC50EN02 Download PDF

Variant:
  • ZAC50EN02 - 4-Port Industrial Ethernet Switch with PoE Capability
Now $1,154.00
BEFORE   $0.00 Now $1,154.00
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Connect effortlessly with this versatile switch, designed to accommodate up to four Industrial Ethernet devices It features two Power over Ethernet (PoE) ports that deliver essential power to connected devices Additionally, you can integrate up to four PNP sensors and actuators through the two digital I/O ports, making it a practical solution for your industrial connectivity needs.

Features and Benefits:

    •2 digital I/O ports.

    •2 PoE-capable ports.

    •4 Industrial Ethernet ports.

    •High protection class IP67.

    •Rugged aluminium housing.

    •Short Circuit Protection.

    •Overload Protection.

    •Reverse Polarity Protection.

    •VLAN Prioritization.

    •Auto-Crossover.

    •Auto-Negotiating.

    •Auto-Polarity.

Specifications:

 Supply Voltage 18 ... 32 V
 Power consumption of device max. 0.25 A
 Power consumption of system max. 2 A
 Max. PoE Capacity 25 W
 Max. Switching Current 0.6 A
 max. total current of the digital I/O ports 1 A
 Voltage Drop < 2.5 V
 Temperature Range -25 ... 60 °C
 PoE Ports 2
 Number of digital I/O ports 2
 Supported PoE Standard IEEE802.3af, IEEE802.at
 Supported PoE Classes Class 0, 1, 2, 3
 Transmission rate 10/100 Mbit/s
 Transmission Mode Full/Half Duplex
 Switch Mode Store & Forward
 Mechanical Data Aluminum
 Degree of Protection IP67
 Type of Connection Power 2 × 7/8", 5-pin
 Type of Connection Industrial Ethernet Ports 2 × M12; 4-pin
 Type of Connection PoE Ports 2 × M12; 8-pin
 Type of connection digital I/O ports 2 × M12; 4-pin
 Web server yes
 Output EtherNet/IP yes
 Power Source Equipment for PoE yes
