    SEFG611 - Compact Safety Light Curtain with Flexibility and Easy Setup

    SEFG611 - Compact Safety Light Curtain with Flexibility and Easy Setup

    SKU: SEFG611   Download PDF

    Select a Variant:
    • SEFG611 - Compact Safety Light Curtain with Flexibility and Easy Setup
    Qty:
    Now $1,803.00   Web pricing policy
    BEFORE   $0.00 Now $1,803.00 Web pricing policy
    Sold out
    Shipping calculated at checkout.
    IN STOCK
    Shipping Available
    Free shipping on orders above $1000. *Wires and cables only.
    View full details
    Product Information Resources Reviews
    Product Information

    Description:

    Enhance safety with the versatile light curtain, designed for easy integration into various systems, thanks to its smart mounting technology and compact design Aligning the emitter and receiver is made effortless with the visible red light and a signal strength indicator The intuitive wTeach2 software simplifies settings and diagnostics via the IO-Link interface, while configurations can be conveniently saved to a microSD card for quick replication across multiple units.

    With comprehensive blanking and muting options, this safety curtain provides tailored solutions for securely moving objects in and out of hazardous areas.

    Features and Benefits:

      •Simple configuration and diagnosis with wTeach2 software.

      •Higher levels of safety and availability thanks to intelligent muting functions.

      •Multifunctional thanks to measuring function.

      •Quick duplication of settings via microSD memory card.

    Specifications:

     Range 0.25 ... 20 m
     Housing Length (L) 258 mm
     Safety Field Height (SFH) 159 mm
     Resolution 30 mm
     Light Source Red Light
     Max. Ambient Light 10,000 Lux
     Opening Angle ± 2.5 °
     Sensor Type Receiver
     Supply Voltage 19.2 ... 28.8 V DC
     Current Consumption (Ub = 24 V) ≤ 350 mA
     Response Time 8.2 ms
     Response time (special) 11.8 ms
     Temperature Range -30 ... 55 °C
     Storage temperature -30 ... 70 °C
     Number of safety outputs (OSSDs) 2
     Safety Output Voltage Drop ≤ 2.3 V
     PNP Safety Output / Switching Current ≤ 300 mA
     Number of Signal Outputs 1
     Signal Output Voltage Drop < 2.5 V
     Signal Output / Switching Current < 100 mA
     Short Circuit Protection yes
     Overload Protection yes
     Interface IO-Link V1.1
     Protection Class III
     Housing Material Aluminum, anodised
     Optic Cover Plastic, PC
     Degree of Protection IP65, IP67
     Connection M12 × 1; 8-pin
     ESPE Type (EN 61496) 4
     Performance Level (EN ISO 13849-1) Cat. 4 PL e
     PFHD ≤ 1.8 × 10-8
     Mission Time TM (EN ISO 13849-1) 20 a
     Safety Integrity Level (EN 61508) SIL3
     Safety Integrity Level (EN 62061) SILCL3
     Function Hand Protection
     Output IO-Link yes
