S2FP001 - High Force Electromechanical Guard Locking Device, 1150 N

S2FP001 - High Force Electromechanical Guard Locking Device, 1150 N

SKU: S2FP001 Download PDF

Variant:
  • S2FP001 - High Force Electromechanical Guard Locking Device, 1150 N
Now $427.00
BEFORE   $0.00 Now $427.00
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing a powerful electromechanical guard locking device that delivers a robust locking force of 1150 N, ensuring optimal security with just one unit needed to achieve the Cat 4 PL e safety standard (EN ISO 13849-1) When connected in series, it maintains consistent safety levels, reaction times, and risk times Featuring advanced diagnostic capabilities, this device enhances system reliability while simplifying both installation and maintenance processes.

Its innovative star handle design is particularly ideal for both rotary and sliding door applications.

Features and Benefits:

    •Performance Level: Cat. 4 PL e.

    •Power to unlock principle.

    •Continuously monitored locking force of 1150 N.

    •Extensive diagnosis functions.

    •Simplified installation and maintenance.

    •Unique star handle operating concept for rotary and sliding doors.

Specifications:

 Supply Voltage 20.4 ... 26.4 V DC
 Response Time ≤ 100 ms
 Risk time ≤ 200 ms
 Temperature Range 0 ... 60 °C
 Storage temperature -10 ... 90 °C
 Safety Output OSSD
 Number of safety outputs (OSSDs) 2
 Safety Output / Switching Current 250 mA
 Number of Signal Outputs 1
 Signal output switching current 50 mA
 Short Circuit Protection yes
 Protection Class III
 Housing Material Plastic
 Degree of Protection IP67, IP66, IP69
 Connection M12 × 1; 8-pin
 Latching Force, typical 25 / 50 N
 Operating principle RFID
 Coding Standard
 Performance Level (EN ISO 13849-1) Cat. 4 PL e *
 PFHD 5,20 × E-10 1/h *
 Safety Integrity Level (EN 61508) SIL3*
 Safety Integrity Level (EN 62061) SILCL3*
 PDDB (EN 60947-5-3) yes
 Locking Device Power to unlock principle
 Locking force F (Zh) 1,150 N
 Function Series Connection yes
 Monitored lock yes
 Mechanical Detent Mechanism yes
 Detent Mechanism yes
 Auxiliary release yes
