ODX402P0088 - 15-Port Fiber-Optic Amplifier with Display and IO-Link

ODX402P0088 - 15-Port Fiber-Optic Amplifier with Display and IO-Link

SKU: SKU: ODX402P0088   Download PDF

Select a Variant:
  • ODX402P0088 - 15-Port Fiber-Optic Amplifier with Display and IO-Link
Qty:
Regular price Now $467.00   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $467.00 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Enhance your sensor capabilities with the Fiber-optic amplifier, designed to connect three wenglor fiber-optic cables effortlessly This versatile module allows you to expand your system by linking up to 12 additional modules, accommodating a total of 15 fiber-optic cables For user-friendly operation, it boasts a graphic display that simplifies sensor configuration through an intuitive menu You can easily monitor signal strengths and switching thresholds, presented as either numeric displays or bar graphs.

Efficiency is further amplified with the inclusion of programming features and quick diagnostic tools available through the IO-Link interface.

Features and Benefits:

    •Recognition of transparent objects.

    •Basic module design.

    •Menu-driven settings for user convenience.

    •Modular system with the connection of 12 add-on modules.

    •Easy setup and programming via graphic display.

    •Quick diagnostics through IO-Link interface.

Specifications:

 Optical Data - Switching Hysteresis < 15 %
 Optical Data - Light Source Red Light
 Optical Data - Service Life 100,000 h (T = +25 °C)
 Optical Data - Max. Ambient Light 10,000 Lux
 Electrical Data - Supply Voltage 18 ... 30 V DC
 Electrical Data - Current Consumption (Ub = 24 V) < 70 mA
 Electrical Data - Switching Frequency 2 kHz
 Electrical Data - Response Time 250 µs
 Electrical Data - On-/Off-Delay 0 ... 10,000 ms
 Electrical Data - Temperature Drift < 10 %
 Electrical Data - Temperature Range -25 ... 60 °C
 Electrical Data - Switching Output - Voltage Drop < 2.5 V
 Electrical Data - Switching Output / Switching Current 100 mA
 Electrical Data - Short Circuit Protection yes
 Electrical Data - Reverse Polarity Protection yes
 Electrical Data - Overload Protection yes
 Electrical Data - Teach Mode NT, MT, ZT, DT, FT, HT, TP
 Electrical Data - Interface IO-Link V1.0
 Electrical Data - IO-Link Parameter > 12
 Mechanical Data - Setting Method Menu (OLED)
 Mechanical Data - Housing Material Plastic, ABS and PC
 Mechanical Data - Degree of Protection IP50
 Mechanical Data - Connection M12 × 1; 4+8-pin
 Mechanical Data - DIN-Rail mounting 35 mm
 Safety-relevant Data - MTTFd (EN ISO 13849-1) 347.83 a
 General Data - Speed Measurement X
 General Data - Selectable menu language X
 General Data - Password Protection X
 General Data - Logic Output AND / OR
 General Data - Output Contamination Output yes
 General Data - IO-Link yes
 General Data - PNP NO yes
 Adjustable parameters - Output Push-pull, NPN, PNP
 Adjustable parameters - Contamination Output Circuit NC, NC/NO, NO
 Other parameters Off-delay, On-delay, Teach-in mode
