OCP662X0080 - High-Resolution Laser Distance Sensor with RS-232 Output

OCP662X0080 - High-Resolution Laser Distance Sensor with RS-232 Output

SKU: OCP662X0080   Download PDF

Select a Variant:
  • OCP662X0080 - High-Resolution Laser Distance Sensor with RS-232 Output
Qty:
Now $665.00   Web pricing policy
BEFORE   $0.00 Now $665.00 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Enhance your measurement accuracy with these advanced sensors featuring high-resolution CMOS line and DSP technology They determine distances through precise angle measurements, effectively eliminating discrepancies in switching points due to variations in material, color, or brightness Two separate switching outputs allow users to set two distinct thresholds along with an adjustable delay time—modifiable in 10 ms increments.

Additionally, you can activate sensor functions and retrieve data through the convenient RS-232 interface.

Features and Benefits:

    •CMOS line array.

    •Highly accurate switching distance.

    •Minimal switching hysteresis.

    •Special coated optics.

Specifications:

 Range 660 mm
 Setting Range 60 ... 660 mm
 Switching Hysteresis < 1 %
 Light Source Laser (red)
 Wavelength 655 nm
 Service Life (T = +25 °C) 100,000 h
 Laser Class (EN 60825-1) 1
 Max. Ambient Light 10,000 Lux
 Electrical Data Supply Voltage 10 ... 30 V DC
 Current Consumption (Ub = 24 V) < 50 mA
 Switching Frequency 100 Hz
 Response Time < 5 ms
 On-/Off-Delay (RS-232) 0 ... 1 s
 Temperature Drift < 50 µm/K
 Temperature Range -25 ... 60 °C
 Number of Switching Outputs 2
 Switching Output Voltage Drop < 1.5 V
 Switching Current 200 mA
 Short Circuit Protection yes
 Reverse Polarity Protection yes
 Teach Mode HT, VT, TP
 Transmission rate 38,400 Bd
 Protection Class III
 FDA Accession Number 1120728-000
 Setting Method Teach-In
 Housing Material Plastic, ABS, Plastic, PC
 Coated Optics yes
 Degree of Protection IP67
 Connection M12 × 1; 8-pin
 Optic Cover Plastic, PMMA
 Output Error Output yes
 PNP NO yes
 RS-232 Interface yes
