OCP352H0180 - High-Resolution Laser Distance Sensor with Analog Output

OCP352H0180 - High-Resolution Laser Distance Sensor with Analog Output

SKU: OCP352H0180 Download PDF

Variant:
  • OCP352H0180 - High-Resolution Laser Distance Sensor with Analog Output
Now $1,239.00
BEFORE   $0.00 Now $1,239.00
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Experience precision with these advanced sensors, utilizing high-resolution CMOS line and DSP technology to accurately measure distance through angular measurement This innovative design nearly eliminates discrepancies due to variations in material, color, and brightness Additionally, the built-in analogue output can be easily configured to provide either a voltage range of 0 to 10 V (or 10 to 0 V) or a current range of 4 to 20 mA (or 20 to 4 mA), ensuring versatility for various applications.

Features and Benefits:

    •High resolution: 50 µm (resolution-mode).

    •Linearity: 0.15 % (resolution-mode).

    •Zoom function.

    •Measured value independent of material, color and brightness.

    •Working Range: 50 ... 350 mm.

    •Measuring Rate: 500 /s.

Specifications:

 Resolution Mode Calculated maximum reproducibility 1,200 µm
 Reproducibility 1 Sigma 400 µm
 Linearity Deviation 1,000 µm
 Light Source Laser (red)
 Wavelength 660 nm
 Service Life (T = +25 °C) 100,000 h
 Laser Class (EN 60825-1) 1
 Max. Ambient Light 10,000 Lux
 Supply Voltage 18 ... 30 V DC
 Current Consumption (Ub = 24 V) < 80 mA
 Measuring Rate (Resolution-Mode) 250 /s
 Response Time 2,000 µs
 Temperature Drift < 75 µm/K
 Temperature Range -25 ... 50 °C
 Analog Output yes
 Load Current Voltage Output < 1 mA
 Current Output Load Resistance < 500 Ohm
 Interface RS-232
 Transmission Rate 38,400 Bd
 Protection Class III
 MTTFd (EN ISO 13849-1) 713.97 a
 Output Error Output yes
 RS-232 Interface yes
 Degree of Protection IP67
 Housing Material Plastic, ABS; Plastic, PC
 Optic Cover Plastic, PMMA
