FXTT023 - Precision Temperature Sensor for Liquids and Gases with IO-Link

FXTT023 - Precision Temperature Sensor for Liquids and Gases with IO-Link

SKU: FXTT023 Download PDF

Variant:
  • FXTT023 - Precision Temperature Sensor for Liquids and Gases with IO-Link
Now $479.00
BEFORE   $0.00 Now $479.00
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

The weFlux² Temperature Sensors provide accurate readings for both liquid and gas temperatures within closed piping systems Depending on your chosen configuration, you can select from two switching outputs, a combination of one switching output and one analog output, or a single 2-wire analog output These outputs can be easily customized through IO-Link, allowing for versatile adjustment based on your specific application needs.

Features and Benefits:

    •FDA compliant.

    •Ready for Industry 4.0 with IO-Link 1.1.

    •Response time T90: < 2 seconds.

    •Temperature measuring range: -50 ... +150° C.

    •Temperature measurement of liquids and gases in closed piping systems..

Specifications:

 Temperature Measurement Range -50 ... 150 °C
 Setting Range -50 ... 150 °C
 Medium Liquids, gases
 Measuring error ± 0.5 °C
 Resolution > 11 bit
 Response Time < 2 s
 Ambient temperature -25 ... 80 °C
 Storage temperature -25 ... 80 °C
 Pressure Resistance 100 bar
 Current Consumption (Ub = 24 V) < 15 mA
 Number of Switching Outputs 2
 Switching Output / Switching Current ± 100 mA
 Analog Output 4...20 mA
 Short Circuit Protection yes
 Reverse Polarity Protection yes
 Protection Class III
 Interface IO-Link V1.1
 Housing Material Stainless steel, V4A (1.4404/316L)
 Degree of Protection IP68, IP69K
 Connection M12 × 1; 4-pin
 Process Connection G 1/2" CIP-capable
 Process Connection Length (PCL) 143.5 mm
 Probe Length (PL) 100 mm
 MTTFd (EN ISO 13849-1) 1,198.4 a
 Adjustable parameters 0...10 V, 4...20 mA, Push-pull, NPN, PNP, NC, NC/NO, NO
 2 switching points
 Selectable measurement range
