FXTT002 - Adjustable Temperature Sensor for Liquids and Gases with IO-Link

SKU: SKU: FXTT002 Download PDF

Variant:

FXTT002 - Adjustable Temperature Sensor for Liquids and Gases with IO-Link

Now $418.00

~~BEFORE $0.00~~ Now $418.00

Sold out

Web pricing policy Shipping calculated at checkout.

IN STOCK

Shipping Available

Free shipping on orders above $1000.* Only on standard purchases of cables and wires.

View full details

Product Information Resources Reviews

Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Experience accurate temperature monitoring with the weFlux² Temperature Sensors, designed for optimal performance in closed piping systems containing liquids and gases You have the flexibility to choose between configurations featuring either two switching outputs, one switching output paired with one analog output, or a single 2-wire analog output Utilize IO-Link to customize your outputs according to your specific application needs, ensuring a perfect fit for your system requirements.

Features and Benefits:

•FDA compliant.

•Ready for Industry 4.0 with IO-Link 1.1.

•Temperature measuring range: -50 ... +150° C.

•Response time T90: < 2 seconds.

•Temperature measurement of liquids and gases in closed piping systems.

Specifications:

Temperature Measurement Range	-50 ... 150 °C
Setting Range	-50 ... 150 °C
Medium	Liquids, gases
Measuring error	± 0.5 °C
Resolution	> 11 bit
Response Time	< 2 s
Ambient temperature	-25 ... 80 °C
Storage temperature	-25 ... 80 °C
Pressure Resistance	100 bar
Electrical Data	{'2-wire supply power': '12 ... 32 V DC', '3-wire supply power': '12 ... 32 V DC', 'Current Consumption (Ub = 24 V)': '< 15 mA', 'Number of Switching Outputs': '2', 'Switching Output / Switching Current': '± 100 mA', 'Switching Output Voltage Drop': '< 1.5 V DC', 'Analog Output': '4...20 mA', 'Short Circuit Protection': 'yes', 'Reverse Polarity Protection': 'yes', 'Protection Class': 'III', 'Interface': 'IO-Link V1.1'}
Mechanical Data	{'Setting Method': 'IO-Link', 'Housing Material': 'Stainless steel, V4A (1.4404/316L)', 'Material in contact with media': 'Stainless steel, V4A (1.4404/316L)', 'Degree of Protection': 'IP69K , IP68 ', 'Connection': 'M12 × 1; 4-pin', 'Process Connection': 'Cutting/locking ring', 'Process Connection Length (PCL)': '209 mm', 'Probe Length (PL)': '200 mm'}
Safety-relevant Data	{'MTTFd (EN ISO 13849-1)': '1,198.4 a', 'Analog Output': 'yes', 'Configurable as PNP/NPN/Push-Pull': 'yes', 'Switchable to NC/NO': 'yes', 'IO-Link': 'yes', 'Adjustable parameters': 'Analog output 0...10 V, 4...20 mA'}
