FXFF152 - Compact Flow Sensor with Dual Outputs for Liquid Flow Measurement

FXFF152 - Compact Flow Sensor with Dual Outputs for Liquid Flow Measurement

SKU: FXFF152 Download PDF

Variant:
  • FXFF152 - Compact Flow Sensor with Dual Outputs for Liquid Flow Measurement
Now $401.00
BEFORE   $0.00 Now $401.00
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the weFlux² Flow Sensors, engineered for precision in flow measurement These sensors simultaneously capture both flow velocity and the temperature of aqueous liquids, regardless of the orientation or flow direction With the ability to reduce the number of measuring points and a variety of sensor options, these devices offer unparalleled flexibility for installation within closed piping systems.

The compact housing includes an integrated analysis module for streamlined performance.

Features and Benefits:

    •2 analog outputs: 4 ... 20 mA.

    •FDA compliant.

    •A single sensor for flow and temperature.

    •Measurement independent of flow direction and installation position.

Specifications:

 Measuring Range 10 ... 400 cm/s
 Temperature of the medium, flow measurement 0 ... 125 °C
 Temperature of the medium, temperature measurement -25 ... 150 °C
 Setting Range 10 ... 400 cm/s
 Medium Water
 Measuring error (total) ≤ 2 %
 MTTFd (EN ISO 13849-1) 1,210.41 a
 Response time in case of temperature jump 10 s
 Ambient temperature -25 ... 80 °C
 Storage temperature -25 ... 80 °C
 Pressure Resistance 100 bar
 Supply Voltage 12 ... 32 V DC
 Current Consumption (Ub = 24 V) < 40 mA
 Number of analog outputs 2
 Analog Output 4...20 mA
 Signal source Flow
 Response Time 1 ... 5 s
 Short Circuit Protection yes
 Reverse Polarity Protection yes
 Protection Class III
 Housing Material Stainless steel, V4A (1.4404/316L)
 Degree of Protection IP69K *; IP68 *
 Connection M12 × 1; 4-pin
 Process Connection Length (PCL) 68 mm
 Probe Length (PL) 36 mm
