FXFF119 - Compact Flow Sensor for Liquid Measurement & Temperature Output

FXFF119 - Compact Flow Sensor for Liquid Measurement & Temperature Output

SKU: FXFF119 Download PDF

Variant:
  • FXFF119 - Compact Flow Sensor for Liquid Measurement & Temperature Output
Now $409.00
BEFORE   $0.00 Now $409.00
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the weFlux² Flow Sensors, engineered to provide precise measurements of flow velocity and temperature for aqueous liquids, irrespective of their flow direction or installation position These sensors streamline your setup by reducing the number of measuring points required, while offering a variety of sensor options to enhance flexibility during installation in closed piping systems All functionalities are contained within a compact housing that includes a built-in analysis module for ease of use.

Features and Benefits:

    •2 analog outputs: 4 ... 20 mA.

    •FDA compliant.

    •A single sensor for flow and temperature.

    •Measurement independent of flow direction and installation position.

Specifications:

 Measuring Range 10 ... 400 cm/s
 Temperature of the medium, flow measurement 0 ... 125 °C
 Temperature of the medium, temperature measurement -25 ... 150 °C
 Setting Range 10 ... 400 cm/s
 Medium Water
 Measuring error (total) ≤ 2 %
 MTTFd (EN ISO 13849-1) 1,210.41 a
 Response time in case of temperature jump 10 s
 Ambient temperature -25 ... 80 °C
 Storage temperature -25 ... 80 °C
 Pressure Resistance 100 bar
 Supply Voltage 12 ... 32 V DC
 Current Consumption (Ub = 24 V) < 40 mA
 Number of analog outputs 2
 Response Time 1 ... 5 s
 Short Circuit Protection yes
 Reverse Polarity Protection yes
 Protection Class III
 Housing Material Stainless steel, V4A (1.4404/316L)
 Material in contact with media Stainless steel, V4A (1.4404/316L)
 Degree of Protection IP69K, IP68
 Connection M12 × 1; 4-pin
 Process Connection G 1/2"
 Process Connection Length (PCL) 90.5 mm
 Probe Length (PL) 50 mm
 Output Analog output flow yes
 Output Analog output temperature yes
