FXFF035 - IO-Link Aqueous Liquid Flow Sensor with Adjustable Outputs

FXFF035 - IO-Link Aqueous Liquid Flow Sensor with Adjustable Outputs

SKU: FXFF035 Download PDF

Variant:
  • FXFF035 - IO-Link Aqueous Liquid Flow Sensor with Adjustable Outputs
Now $401.00
BEFORE   $0.00 Now $401.00
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the weFlux² flow sensor, expertly engineered to gauge both the flow velocity and temperature of aqueous liquids This versatile device operates flawlessly regardless of its position or the direction of flow, allowing for enhanced installation flexibility within closed piping systems Its innovative design minimizes the need for multiple measuring points Depending on your requirements, this sensor can be configured to provide either two switching outputs or a combination of one switching output and one analog output, all adjustable via IO-Link for customized application solutions.

Features and Benefits:

    •Single sensor for both flow and temperature measurements.

    •FDA compliant.

    •Ready for Industry 4.0 with IO-Link 1.1.

    •Measurement independent of flow direction and installation position.

Specifications:

 Measuring Range: 10 ... 400 cm/s
 Temperature of the medium, flow measurement: 0 ... 125 °C
 Temperature of the medium, temperature measurement: -25 ... 150 °C
 Setting Range: 10 ... 400 cm/s
 Medium: Water
 Measuring error (total): ≤ 2 %
 MTTFd (EN ISO 13849-1): 1,210.41 a
 Response time in case of temperature jump: 10 s
 Ambient temperature: -25 ... 80 °C
 Storage temperature: -25 ... 80 °C
 Pressure Resistance: 100 bar
 Electrical Data Supply Voltage: 12 ... 32 V DC
 Current Consumption (Ub = 24 V): < 40 mA
 Number of Switching Outputs: 2
 Number of analog outputs: 1
 Analog Output: 4...20 mA
 Signal source: Flow
 Response Time: 1 ... 5 s
 Switching Output / Switching Current: ± 100 mA
 Voltage Drop: < 2 V
 Load Current Voltage Output: ≤ 20 mA
 Short Circuit Protection: yes
 Reverse Polarity Protection: yes
 Protection Class: III
 Housing Material: Stainless steel, V4A (1.4404/316L)
 Material in contact with media: Stainless steel, V4A (1.4404/316L)
 Degree of Protection: IP69K
 Connection: M12 × 1; 4-pin
 Process Connection: G 1/4"
 Process Connection Length (PCL): 67.5 mm
 Probe Length (PL): 32 mm
 Output Analog output flow: yes
 IO-Link: yes
 PNP NO: yes
