FXFF020 - Versatile Flow Sensor for Liquid Temperature & Velocity Measurement

FXFF020 - Versatile Flow Sensor for Liquid Temperature & Velocity Measurement

SKU: FXFF020 Download PDF

Variant:
  • FXFF020 - Versatile Flow Sensor for Liquid Temperature & Velocity Measurement
Now $401.00
BEFORE   $0.00 Now $401.00
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the innovative weFlux² flow sensors, expertly crafted to measure both flow velocity and temperature of water-based liquids, regardless of their orientation or direction of flow This groundbreaking design reduces the number of necessary measurement points and offers a wider variety of sensor options, allowing for maximum flexibility when integrating into closed piping systems You can choose between two switching outputs or a combination of one switching output and one analog output, tailored to meet specific application needs.

Thanks to IO-Link compatibility, the outputs can be customized to seamlessly fit the requirements of your project This versatile sensor boasts a single unit for both flow and temperature measurements, adheres to FDA standards, and is ready for Industry 40 with its IO-Link 11 support Experience unprecedented freedom in installation with its capability to function independently of flow direction and positioning.

Features and Benefits:

    •A single sensor for flow and temperature.

    •FDA compliant.

    •Ready for Industry 4.0 with IO-Link 1.1.

    •Measurement independent of flow direction and installation position.

Specifications:

 Measuring Range 10 ... 400 cm/s
 Temperature of the medium, flow measurement 0 ... 125 °C
 Temperature of the medium, temperature measurement -25 ... 150 °C
 Setting Range 10 ... 400 cm/s
 Medium Water
 Measuring error (total) ≤ 2 %
 MTTFd (EN ISO 13849-1) 1,210.41 a
 Response time in case of temperature jump 10 s
 Ambient temperature -25 ... 80 °C
 Storage temperature -25 ... 80 °C
 Pressure Resistance 100 bar
 EMC DIN EN 61326-1
 Shock resistance per DIN IEC 68-2-27 30 g / 11 ms
 Vibration resistance per DIN IEC 60068-2-6 5 g (10...2000 Hz)
 Supply Voltage 12 ... 32 V DC
 Current Consumption (Ub = 24 V) < 40 mA
 Number of Switching Outputs 2
 Number of analog outputs 1
 Analog Output 4...20 mA
 Response Time 1 ... 5 s
 Switching Current ± 100 mA
 Voltage Drop < 2 V
 Load Current Voltage Output ≤ 20 mA
 Short Circuit Protection yes
 Reverse Polarity Protection yes
 Protection Class III
 Interface IO-Link V1.1
 Setting Method IO-Link
 Housing Material Stainless steel, V4A (1.4404/316L)
 Material in contact with media Stainless steel, V4A (1.4404/316L)
 Degree of Protection IP69K *
 Connection M12 × 1; 4-pin
 Process Connection G 1/2"
 Process Connection Length (PCL) 72.5 mm
 Probe Length (PL) 32 mm
 Output Analog output flow yes
 IO-Link yes
 PNP NO yes
 Adjustable parameters 2 switching points
 Selectable measurement range
