FXFF019 - Versatile Flow Sensor with Temperature Measurement and IO-Link

FXFF019 - Versatile Flow Sensor with Temperature Measurement and IO-Link

SKU: FXFF019 Download PDF

Variant:
  • FXFF019 - Versatile Flow Sensor with Temperature Measurement and IO-Link
Now $409.00
BEFORE   $0.00 Now $409.00
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the innovative Flow Sensor with IO-Link from weFlux², engineered to accurately measure both flow velocity and temperature in aqueous liquids, regardless of installation position or flow direction This sensor design minimizes the need for multiple measurement points, providing exceptional flexibility for closed piping systems Depending on your application needs, you can choose between two switching outputs or a combination of one switching output and one analog output.

The outputs are easily customizable through IO-Link, allowing you to tailor the sensor's functions to suit specific requirements Typically dispatched within 7 days of ordering, this flow sensor is your ideal solution for versatile flow measurement.

Features and Benefits:

    •A single sensor for flow and temperature.

    •FDA compliant.

    •Ready for Industry 4.0 with IO-Link 1.1.

    •Measurement independent of flow direction and installation position.

Specifications:

 Measuring Range (Flow) 10 ... 400 cm/s
 Temperature of the medium (Flow measurement) 0 ... 125 °C
 Temperature of the medium (Temperature measurement) -25 ... 150 °C
 Setting Range 10 ... 400 cm/s
 Medium Water
 Measuring error (total) ≤ 2 %
 MTTFd (EN ISO 13849-1) 1,210.41 a
 Response time (temperature jump) 10 s
 Ambient temperature -25 ... 80 °C
 Storage temperature -25 ... 80 °C
 Pressure Resistance 100 bar
 EMC DIN EN 61326-1
 Shock resistance 30 g / 11 ms
 Vibration resistance 5 g (10...2000 Hz)
 Supply Voltage 12 ... 32 V DC
 Current Consumption (Ub = 24 V) < 40 mA
 Number of Switching Outputs 2
 Number of analog outputs 1
 Analog Output 4...20 mA
 Signal source Flow
 Response Time 1 ... 5 s
 Switching Current ± 100 mA
 Load Current Voltage Output ≤ 20 mA
 Short Circuit Protection yes
 Reverse Polarity Protection yes
 Protection Class III
 Interface IO-Link V1.1
 Setting Method IO-Link
 Housing Material Stainless steel, V4A (1.4404/316L)
 Material in contact with media Stainless steel, V4A (1.4404/316L)
 Degree of Protection IP69K
 Connection M12 × 1; 4-pin
 Process Connection G 1/2"
 Process Connection Length (PCL) 90.5 mm
 Probe Length (PL) 50 mm
 Output Analog output flow yes
 IO-Link yes
 PNP NO yes
 Adjustable parameters Output Analog Output
 Analog output options 0...10 V, 4...20 mA
 Other parameters 2 switching points
