CP70QXVT80 - Precision Laser Distance Sensor with Dual Outputs and RS-232 Interface

CP70QXVT80 - Precision Laser Distance Sensor with Dual Outputs and RS-232 Interface

SKU: CP70QXVT80 Download PDF

Variant:
  • CP70QXVT80 - Precision Laser Distance Sensor with Dual Outputs and RS-232 Interface
Now $722.00
BEFORE   $0.00 Now $722.00
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Experience precision measurement with these advanced sensors that utilize high-resolution CMOS line and DSP technology for accurate distance detection through angle measurements This innovative design minimizes discrepancies at switching points caused by variations in material, color, and brightness The sensors come equipped with dual independent switching outputs, which allow users to establish two distinct switching thresholds.

You can also customize on-delay and off-delay times in 10 ms increments according to your needs Additionally, the functionality of the sensors can be easily activated, and data can be transmitted through the RS-232 interface, enhancing versatility for various applications.

Features and Benefits:

    •CMOS line array.

    •Highly accurate switching distance.

    •Minimal switching hysteresis.

    •Switching point independent of material, color and brightness.

Specifications:

 Range 660 mm
 Setting Range 60 ... 660 mm
 Switching Hysteresis < 1 %
 Light Source Laser (red)
 Wavelength 655 nm
 Service Life (T = +25 °C) 100,000 h
 Laser Class (EN 60825-1) 2
 Max. Ambient Light 10,000 Lux
 Electrical Data {'Supply Voltage': '10 ... 30 V DC', 'Current Consumption (Ub = 24 V)': '< 50 mA', 'Switching Frequency': '250 Hz', 'Response Time': '2 ms', 'On-/Off-Delay (RS-232)': '0 ... 1 s', 'Temperature Drift': '< 50 µm/K', 'Temperature Range': '-25 ... 60 °C', 'Number of Switching Outputs': '2', 'Switching Output Voltage Drop': '< 1.5 V', 'Switching Output / Switching Current': '200 mA', 'Short Circuit Protection': 'yes', 'Reverse Polarity Protection': 'yes', 'Teach Mode': 'HT, VT, TP', 'Transmission rate': '38,400 Bd', 'Protection Class': 'III', 'FDA Accession Number': '0820587-000'}
 Mechanical Data {'Setting Method': 'Teach-In', 'Housing Material': 'Plastic, ABS, PC', 'Degree of Protection': 'IP67', 'Connection': 'M12 × 1; 8-pin', 'Optic Cover': 'Plastic, PMMA'}
 Error Output yes
 PNP NO yes
 RS-232 Interface yes
