CP35MHT80 - High-Resolution Laser Distance Sensor with Adjustable Analog Output

CP35MHT80 - High-Resolution Laser Distance Sensor with Adjustable Analog Output

SKU: CP35MHT80   Download PDF

Select a Variant:
  • CP35MHT80 - High-Resolution Laser Distance Sensor with Adjustable Analog Output
Qty:
Now $1,239.00   Web pricing policy
BEFORE   $0.00 Now $1,239.00 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Experience precision with this advanced sensor, which integrates high-resolution CMOS line and DSP technology for accurate distance measurement through angular calculations This innovative design effectively mitigates measurement inconsistencies caused by material, color, or brightness variations Additionally, it offers a versatile analogue output, adjustable for either a voltage range of 0 to 10 V or a current output ranging from 4 to 20 mA, making it adaptable to various applications.

Features and Benefits:

    •Response time: < 1250 µs (speed-mode).

    •High resolution: 50 µm (resolution-mode).

    •Linearity: 0.15 % (resolution-mode).

    •Zoom function.

    •Measured value independent of material, color and brightness.

Specifications:

 Working Range: 50 ... 350 mm
 Measuring Range: 300 mm
 Resolution: 50 µm
 Light Source: Laser (red)
 Wavelength: 660 nm
 Service Life: 100,000 h
 Max. Ambient Light: 10,000 Lux
 Supply Voltage: 18 ... 30 V DC
 Current Consumption: < 80 mA
 Temperature Range: -25 ... 50 °C
 Degree of Protection: IP67
 Weight: 45 g
