CP25QXVT80 - High Precision Laser Distance Sensor with RS-232 Output

CP25QXVT80 - High Precision Laser Distance Sensor with RS-232 Output

SKU: CP25QXVT80 Download PDF

Variant:
  • CP25QXVT80 - High Precision Laser Distance Sensor with RS-232 Output
Now $577.00
BEFORE   $0.00 Now $577.00
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Experience precise distance measurement with this advanced laser distance sensor Utilizing high-resolution CMOS line and DSP technology, it effectively calculates distance through angle measurement, reducing discrepancies associated with materials, colors, and brightness variations Equipped with two independent switching outputs, this sensor allows for customizable configurations of switching thresholds and an adjustable delay time in 10 ms increments.

You can easily activate its functions and obtain readings via the RS-232 interface, ensuring versatility and efficiency in your projects.

Features and Benefits:

    •Minimal switching hysteresis.

    •Switching point independent of material, color and brightness.

    •CMOS line array.

    •Highly accurate switching distance.

Specifications:

 Optical Data Range 240 mm
 Setting Range 40 ... 240 mm
 Switching Hysteresis < 0.5 %
 Light Source Laser (red)
 Wavelength 655 nm
 Service Life (T = +25 °C) 100,000 h
 Laser Class (EN 60825-1) 2
 Max. Ambient Light 10,000 Lux
 Light Spot Diameter see Table 1
 Electrical Data Supply Voltage 10 ... 30 V DC
 Current Consumption (Ub = 24 V) < 50 mA
 Switching Frequency 500 Hz
 Response Time 1 ms
 On-/Off-Delay (RS-232) 0 ... 1 s
 Temperature Drift < 15 µm/K
 Temperature Range -25 ... 60 °C
 Number of Switching Outputs 2
 Switching Output Voltage Drop < 1.5 V
 Switching Output / Switching Current 200 mA
 Short Circuit Protection yes
 Reverse Polarity Protection yes
 Teach Mode HT, VT, TP
 Transmission rate 38,400 Bd
 Protection Class III
 FDA Accession Number 0820586-000
 Mechanical Data Setting Method Teach-In
 Housing Material Plastic, ABS, Plastic, PC
 Degree of Protection IP67
 Connection M12 × 1; 8-pin
 Optic Cover Plastic, PMMA
 Output Error Output yes
 PNP NO yes
 RS-232 Interface yes
 Adjustable parameters Output Push-pull, NPN, PNP, Error Output
 Other parameters Off-delay, On-delay, Exposure time, Teach mode, Switching hysteresis, Laser light
