CP08MHT80 - High-Precision Distance Sensor with Analog Output Options

CP08MHT80 - High-Precision Distance Sensor with Analog Output Options

SKU: CP08MHT80 Download PDF

Variant:
  • CP08MHT80 - High-Precision Distance Sensor with Analog Output Options
Now $1,239.00
BEFORE   $0.00 Now $1,239.00
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Experience precision with these advanced sensors that leverage high-resolution CMOS line and DSP technology to accurately measure distances through angular computation This innovative design nearly eradicates discrepancies caused by variations in material, color, and brightness Moreover, the built-in analogue output is versatile, allowing you to set it for either a voltage range of 010 V (100 V) or a current range of 4.

20 mA (204 mA).

Features and Benefits:

    •Response time: < 660 µs (speed-mode).

    •High resolution: 8 µm (resolution-mode).

    •Linearity: 0.1 % (resolution-mode).

    •Zoom function.

    •Measured value independent of material, color and brightness.

Specifications:

 Working Range 30 ... 80 mm
 Measuring Range 50 mm
 Resolution 8 µm
 Resolution (Speed-Mode) 12 µm
 Linearity 0.1 %
 Linearity (Speed-Mode) 0.2 %
 Linearity Deviation 50 µm
 Light Source Laser (red)
 Wavelength 660 nm
 Service Life (T = +25 °C) 100,000 h
 Laser Class (EN 60825-1) 2
 Max. Ambient Light 10,000 Lux
 Supply Voltage 18 ... 30 V DC
 Current Consumption (Ub = 24 V) < 80 mA
 Measuring Rate 1,500 /s
 Measuring Rate (Resolution-Mode) 600 /s
 Temperature Drift < 5 µm/K
 Temperature Range -25 ... 50 °C
 Analog Output 0...10 V
 Load Current Voltage Output < 1 mA
 Current Output Load Resistance < 500 Ohm
 Interface RS-232
 Transmission rate 38,400 Bd
 Protection Class III
 Housing Material Plastic, ABS and PC
 Optic Cover Plastic, PMMA
 Degree of Protection IP67
 Connection M12 × 1; 8-pin
 Safety-relevant Data MTTFd (EN ISO 13849-1): 713.97 a
 Output Error Output yes
 Adjustable parameters Analog output: 0...10 V, 4...20 mA
