1938680000 - Active Subbus Module with M8 & M12 Connections
1938680000 - Active Subbus Module with M8 & M12 Connections
SKU: SKU: 1938680000 Download PDF
- 1938680000 - Active Subbus Module with M8 & M12 Connections
- 1938680000 - Active Subbus Module with M8 & M12 Connections
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Introducing the SAI-AU M12 SB 8DO 2A, an advanced active Subbus module that combines essential functionalities while adhering to RoHS standards This versatile module offers multiple connection options, including M8 and M12 plugs, for seamless integration of digital inputs and outputs It operates within a designated voltage range and features diagnostic indicators for easy troubleshooting With the ability to support various input and output configurations, this module also includes protective measures to enhance its performance and reliability.
Features and Benefits:
•Compliant with RoHS standards.
•Short-circuit proof with an error message indicator.
•Reverse polarity protection.
•Suitable for various environmental conditions with an IP67 protection degree.
•Configured input filters for flexibility.
Specifications:
| Height | 32 mm |
| Width | 30 mm |
| Length | 180 mm |
| Net weight | 298 g |
| Operating temperature | 0 °C...60 °C |
| Storage temperature | -25 °C...85 °C |
| Protection degree | IP67 |
| Housing main material | Pocan, PBT |
| Supply voltage | 18 V DC ... 30 V DC |
| Max. total current module | 8 A |
| Input current, high | 2 mA to 15 mA in accordance with EN 61131-2 Type 1 |
| Input current, low | < 15 mA in accordance with EN 61131-2 Type 1 |
| Max. total current outputs | 4 A |
| Digital outputs diagnosis indication | red |
