2760990000 - RoHS Compliant Set of 90 Items, 15.7mm Depth (Pack of 90)
2760990000 - RoHS Compliant Set of 90 Items, 15.7mm Depth (Pack of 90)
SKU: SKU: 2760990000 Download PDF
- 2760990000 - RoHS Compliant Set of 90 Items, 15.7mm Depth (Pack of 90)
- 2760990000 - RoHS Compliant Set of 90 Items, 15.7mm Depth (Pack of 90)
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
This product adheres to RoHS standards and boasts certification number E60693 from cURus It is packaged in boxes containing 90 units each The item measures 157 mm deep, 252 mm tall, and 2103 mm wide, corresponding to 0618 inches, 0992 inches, and 0828 inches in inches Each individual piece has a net weight of 969 grams.
Features and Benefits:
•RoHS compliant with exemptions.
•UL certified under certificate number E60693.
•Insulating material made of PA.
•Rated current between 13.5 A and 16.5 A depending on temperature.
•Operating temperature range from -50 °C to 120 °C.
•V-0 flammability rating.
•Contact material is a copper alloy with tinned surface.
Specifications:
| Depth | 15.7 mm |
| Height | 25.2 mm |
| Width | 21.03 mm |
| Net weight | 9.69 g |
| Rated voltage for pollution degree II/2 | 600 V |
| Rated voltage for pollution degree III/2 | 300 V |
| Rated current, max. number of poles (Tu=20°C) | 13.5 A |
| Rated current, min. number of poles (Tu=40°C) | 16.5 A |
| Operating temperature, min. | -50 °C |
| Operating temperature, max. | 120 °C |
| Rated impulse voltage for pollution degree II/2 | 4,000 V |
| Rated impulse voltage for pollution degree III/2 | 4,000 kV |
