2761060000 - RoHS Compliant Black Set, 49.03mm Wide, 15.7mm Deep (Pack of 40)
2761060000 - RoHS Compliant Black Set, 49.03mm Wide, 15.7mm Deep (Pack of 40)
SKU: SKU: 2761060000 Download PDF
- 2761060000 - RoHS Compliant Black Set, 49.03mm Wide, 15.7mm Deep (Pack of 40)
- 2761060000 - RoHS Compliant Black Set, 49.03mm Wide, 15.7mm Deep (Pack of 40)
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Discover the SET BSCZ/SSC, an efficient product with compact dimensions: 157 mm in depth, 252 mm in height, and 4903 mm in width This item weighs just 2291 grams, making it lightweight and easy to handle Compliant with RoHS standards, it comes in a sophisticated black hue (RAL 9011) and is conveniently packaged with 40 units per box, ideal for bulk purchases.
Features and Benefits:
•Compliant with RoHS exemption 6c.
•UL approved with certificate number E60693.
•Operating temperature range from -50 °C to 120 °C.
•Rated current options ranging from a maximum of 13.5 A to a minimum of 16.5 A.
Specifications:
| Depth | 15.7 mm |
| Height | 25.2 mm |
| Width | 49.03 mm |
| Net weight | 22.91 g |
| Insulating material | PA |
| Rated voltage for pollution degree II/2 | 600 V |
| Rated voltage for pollution degree III/2 | 300 V |
| Rated impulse voltage for pollution degree II/2 | 4,000 V |
| Rated impulse voltage for pollution degree III/2 | 4,000 V |
| UL 94 flammability rating | V-0 |
| Contact material | Cu-alloy |
| Contact surface | tinned |
