2761020000 - RoHS Compliant Set, 25.2mm Height, Box of 60 Items (Pack of 60)
2761020000 - RoHS Compliant Set, 25.2mm Height, Box of 60 Items (Pack of 60)
SKU: SKU: 2761020000 Download PDF
- 2761020000 - RoHS Compliant Set, 25.2mm Height, Box of 60 Items (Pack of 60)
- 2761020000 - RoHS Compliant Set, 25.2mm Height, Box of 60 Items (Pack of 60)
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Introducing the SET BSCZ/SSC 400/08/90/32 SN BK SO, a meticulously crafted product that adheres to RoHS standards and holds a UL certification (E60693) Each box contains 60 units, making it ideal for bulk purchasing With compact dimensions of 157 mm in depth, 252 mm in height, and 3303 mm in width—equivalent to 0618 inches, 0992 inches, and 13 inches—this item is both space-efficient and easy to store.
Lightweight at just 1529 grams, it ensures effortless handling and transport .
Features and Benefits:
•Black color with a similar shade to RAL 9011.
•Compliant with RoHS exemptions.
•Appropriate for extreme temperature conditions ranging from -50 °C to 120 °C.
•UL 94 flammability rating V-0, indicating high safety standards.
Specifications:
| Depth | 15.7 mm |
| Height | 25.2 mm |
| Width | 33.03 mm |
| Net weight | 15.29 g |
| Insulating material | PA |
| Contact material | Cu-alloy |
| Contact surface | tinned |
| Rated current, max. number of poles (Tu=20°C) | 13.5 A |
| Rated current, min. number of poles (Tu=40°C) | 16.5 A |
| Rated voltage for surge voltage class / pollution degree II/2 | 600 V |
| Rated voltage for surge voltage class / pollution degree III/2 | 300 V |
| Rated impulse voltage for surge voltage class / pollution degree II/2 | 4,000 V |
| Rated impulse voltage for surge voltage class / pollution degree III/2 | 4,000 V |
| RoHS Compliance Status | Compliant with exemption |
| REACH SVHC | Lead 7439-92-1 |
