1894750000 - HDC-CM-2BPN2.5 Heavy-Duty Pneumatic Connector, 40.4mm Height

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the HDC-CM-2BPN25 heavy-duty connector, engineered to meet RoHS standards, making it ideal for highly demanding applications This connector boasts a sturdy female hose connection designed specifically for pneumatic systems and incorporates two valves for efficient functionality Constructed from durable glass-fiber-reinforced polyamide, it withstands tough conditions and operates within a wide temperature range of -40 °C to 80 °C.

In terms of dimensions, this module measures 404 mm in height, 114 mm in width, and 34 mm in length, with a net weight of 26 g The classic black color adds a professional touch, and it is equipped with NBR sealing material Additionally, it features a test pressure rating of 10 bar, ensuring reliable performance in various environments.

Features and Benefits:

•RoHS compliant.

•Low smoke according to DIN EN 45545-2.

•UL 94 flammability rating V-0.

•Only compatible with PTFE hoses.

•Constructed from PA 6.6.

Specifications:
