2748410000 - 5-Pole Signal Module, 230V, 16A, Compact Design

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing a versatile signal module that operates on a 230 V power supply with a strong current rating of 16 A This module features five poles and incorporates a user-friendly PUSH IN mechanism paired with an actuator Its compact size requires only one plug-in slot, making it perfect for a wide range of applications.

Features and Benefits:

•Compliant with RoHS and REACH standards.

•Made from polycarbonate material.

•Can handle a range of temperatures from -40 °C to 125 °C.

•Durable with a minimum of 500 plugging cycles.

•Rated impulse voltage of 4 kV.

•Rated for a maximum voltage of 600 V according to UL/CSA.

•Surge voltage category III.

•Flammability rating of V-0.

Specifications:
