1498100000 - 3-Pole Male Insert, 400V 16A, 21x21x36.5mm

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the HDC HA 3 MS male insert, specifically crafted for reliable electrical connections at 400 V and 16 A This insert features a sturdy three-pole design with a secure screw connection Certified under UL file number E92202, it meets strict RoHS standards, ensuring compliance with environmental regulations Constructed from a durable copper alloy, the HDC HA 3 MS boasts impressive chemical resistance ratings, making it suitable for various applications.

Its compact dimensions are 21 mm in width, 21 mm in depth, and 365 mm in height, weighing just 15 g This insert operates efficiently within a wide temperature range of -40 °C to 125 °C Furthermore, the insulation is made from glass-fiber reinforced PC, which is not only UL-listed but also railway-certified, ensuring superior performance and safety in demanding environments.

Features and Benefits:

•RoHS compliant.

•Rated current of 16 A.

•Low smoke according to DIN EN 45545-2.

•Surface is silver passivated.

•Chemical resistance against various substances.

•Volume resistance is ≤2 mΩ.

Specifications:
