1429370000 - 6-Pole 500V Signal Module with Crimp Connection

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing our advanced signal module, engineered to perform efficiently at a voltage of 500 V and supports a current capacity of 16 A This module features 6 poles equipped with crimp connections and is designed to utilize a single plug-in slot for easy installation It adheres to various approvals including RoHS compliance, ensuring it meets stringent safety and environmental standards Additionally, it holds a UL Certificate (No.

E92202) for added reliability Perfect for a range of applications, this component is a dependable choice for your electrical needs.

Features and Benefits:

•Made from polycarbonate with glass fiber reinforcement.

•Insulation resistance of 10^12 Ω.

•Rated for more than 500 plugging cycles.

•Plugging cycles are rated for ≥ 500.

•Rated current as per DIN EN 61984 is 16 A.

•Rated impulse voltage of 6 kV.

•Rated voltage as per DIN EN 61984 is 500 V.

•Rated voltage according to UL/CSA is 600 V.

•Has a UL 94 flammability rating of V-0.

•Pollution severity rated at level 3.

Specifications:
