1975330000 - 5mm PCB Terminal, 10 Poles, 90° Angle, Tinned Pins (Pack of 50)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing a versatile printed circuit board terminal, designed to make your connections efficient and reliable This terminal measures 500 mm and features 10 poles arranged at a precise 90° angle It is equipped with a 32 mm tinned solder pin, ensuring optimal conductivity, and comes in a vibrant orange hue that stands out With a clamping yoke connection system, this terminal easily accommodates conductors up to 6 mm².

Each order is conveniently packaged in boxes, making restocking a breeze.

Features and Benefits:

•IEC rated at 500 V / 32.5 A / 0.5 - 6 mm².

•UL rated at 300 V / 20 A / AWG 26 - AWG 12.

•Wire connection method utilizes a clamping yoke.

•Touch-safe protection according to DIN VDE 0470 IP 20.

•RoHS compliant and safe from harmful substances.

Specifications:
