1157800000 - 91mm Crimp Connector, Copper Alloy for 3,000V Applications

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the HDC HP 550 M 50, your reliable solution for strong electrical connections in demanding environments This component utilizes a crimp connection type and is specifically designed for installations requiring a size of 550 Crafted from durable copper alloy, it supports a maximum operating voltage of 3,000 V and functions effectively at temperatures up to 60°C, catering to a wide range of electrical applications.

The insert features a compact design with a diameter of 43 mm and a length of 91 mm, weighing only 188 g, making it an efficient choice for your installation needs.

Features and Benefits:

•Compliant with RoHS standards.

•Can withstand temperatures ranging from -50 °C to 120 °C.

•Rated for 200 A current according to DIN EN 61984.

•Supports over 500 plugging cycles.

•Copper alloy construction for durability.

Specifications:
