Belden 7203A 24 AWG 4 Pair 41x40 Stranding Bare Copper 300V MachFlex Cable

Description:-

MachFlex for High Flex, 4 Pair 24 AWG (41x40) Bare Copper, PE Insulation, Overall Beldfoil +Tinned Copper Braid (85%) Shield, PVC Outer Jacket, CM.

Insulation:-

• Material: PE - Polyethylene (Foam)
• Nom. Thickness: 0.012 in (0.30 mm)
• Nom. Insulation Diameter: 0.0555 in (1.41 mm)

Outer Shield:-

• Layer: 1
• Shield Type: Tape
• Material: Bi-Laminate (Alum+Poly)
• Coverage [%]: 100%
• Drainwire Type: 24 AWG (41x40) TC - Tinned Copper

• Layer: 2
• Shield Type: Braid
• Material: Tinned Copper (TC)
• Coverage [%]: 90%

Outer Jacket:-

• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.045 in (1.1 mm)
• Nom. Diameter: 0.362 in (9.19 mm)
• Overall Cable Diameter (Nominal): 0.362 in (9.19 mm)

Standards:-

• UL Voltage Rating: 300 V (CM)
• Operating Temperature Range: -20°C to +60°C

Applications:-

• Flex Data, RS-232, RS-485

Specifications:-

• Size (AWG): 24
• No. of Pairs: 4
• Stranding: 41x40
• Conductor Material: BC - Bare Copper
• Part Number: 7203A
