2682640000 - Fast Ethernet IoT Gateway, Dual-Core, -20°C to 60°C Operation

2682640000 - Fast Ethernet IoT Gateway, Dual-Core, -20°C to 60°C Operation

SKU: SKU: 2682640000 Download PDF

Regular price Now $925.73
Regular price BEFORE   $0.00 Sale price Now $925.73
Sold out
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Experience seamless connectivity with the IoT Gateway, expertly crafted for Fast Ethernet Able to operate within a temperature spectrum of -20 °C to 60 °C, it boasts a sturdy design that meets various industry standards, making it ideal for applications that necessitate reliable remote access The gateway is backed by a UL certification (File Number E141197), ensuring it adheres to rigorous safety standards.

It functions with a 24 V DC supply voltage and includes reverse polarity protection for added safety This device supports a range of mobile communication bands and is equipped with multiple interfaces, including Ethernet ports and external antenna connectors Powered by a dual-core processor with 4 GB of flash memory, it excels in handling real-time processing tasks efficiently.

Features and Benefits:

    •Reverse polarity protection.

    •Operating temperature range from -20 °C to 60 °C.

    •Complies with RoHS requirements.

    •Supports a variety of mobile radio interfaces.

    •Provides a reliable cloud-based remote access service.

Specifications:

 Depth 105 mm
 Height 125 mm
 Width 35 mm
 Storage temperature -40 °C to 85 °C
 Humidity 5 to 95 % (non-condensing)
 Protection degree IP20
 Memory (Flash) 4 GB
 Memory (RAM) 1 GB DDR3
 Processor Dual Core ARM Cortex A9, 600 MHz
 Power supply 24 V DC
 Digital inputs 2x >10 V high , <3.6 V low; max. 30 V DC
 Digital outputs 1x 19.2 - 28 V high; max. 1 A
 Ethernet ports 2
 SIM-Card slots 1 Micro-SIM
 USB port 1x USB 2.0 (Type A; max. 500 mA)
 Mobile radio interface LTE (LTE / 4G)
 Safety standards EN 61000-6-3, EN 61000-6-2
