2555660000 - 4.3" IP66 Touch Panel with Resistive Interface
2555660000 - 4.3" IP66 Touch Panel with Resistive Interface
SKU: SKU: 2555660000 Download PDF
- 2555660000 - 4.3" IP66 Touch Panel with Resistive Interface
- 2555660000 - 4.3" IP66 Touch Panel with Resistive Interface
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Discover the versatility of this web-compatible touch panel, showcasing a 43-inch display that utilizes a resistive touch interface Built to withstand harsh conditions, it features front protection with an IP66 rating for optimal durability The touch panel is identified by the general ordering number 2555660000 and holds a cULus certification, under certificate number E512053 Additionally, it adheres to RoHS and REACH guidelines, ensuring compliance regarding hazardous substances, with a specific focus on Lead.
Features and Benefits:
•Display size of 4.3 inches.
•Front protection rated IP66.
•Operating system compatible with Linux and HTML5 browsers.
•Touch screen technology is resistive.
•Has a luminance of 400 cd/m².
•Supports 16 million displayable colors.
Specifications:
| Depth | 36 mm |
| Height | 89 mm |
| Width | 120 mm |
| Wall thickness, min. | 2 mm |
| Wall thickness, max. | 6 mm |
| Storage temperature | -20 °C to +85 °C |
| Operating temperature | 0 °C to +50 °C |
| Humidity | 10 - 95% relative humidity, non-condensing |
| Current consumption Voltage | 24 V |
| Current consumption Current | 0.23 A |
| MTBF with LCD | 5.38 a |
| MTBF without LCD | 93.46 a |
| Protection degree | IP66 |
| Voltage supply | 24 V DC |
| Voltage supply range | 20.4 V to 27.6 V |
| Interfaces | 1x Ethernet 10/100 MBit/s (RJ45) |
| Memory (Flash) | 4 GB |
| Memory (RAM) | 1 GB |
| Processor | Dual Core ARM Cortex-A9, 1 GHz (GPU 2D / GPU 3D support) |
| RoHS Compliance Status | Compliant with exemption |
