1631380000 - 90° Terminal with 10.16mm Spacing and 3.2mm Solder Pin (Pack of 20)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the LU 1016/02/90 4STI 32SN GN BX, a reliable printed circuit board terminal that offers two poles with a convenient spacing of 1016 mm Its design features a 90° angle, complemented by a tinned solder pin measuring 32 mm in length This terminal is presented in a soft pale green color, equipped with a clamping yoke connection that accommodates a maximum clamping range of 16 mm² Packaged neatly in a box, its order number is 1631380000, making it easy to identify for your needs.

Features and Benefits:

•RoHS compliant without exemption.

•Suitable for clamping ranges from 0.14 mm² to 16 mm².

•Can accommodate various conductor types: solid, stranded, and flexible.

•Mounting through THT solder connection.

•Touch-safe protection according to DIN VDE standards.

•Meets multiple IEC and CSA testing standards.

Specifications:
