1049060000 - Pebble Grey 4-Pole Terminal, 4.5mm Solder Pin, 90° Angle (Pack of 20)

1049060000 - Pebble Grey 4-Pole Terminal, 4.5mm Solder Pin, 90° Angle (Pack of 20)

SKU: SKU: 1049060000   Download PDF

Select a Variant:
  • 1049060000 - Pebble Grey 4-Pole Terminal, 4.5mm Solder Pin, 90° Angle (Pack of 20)
Qty:
Regular price Now $346.73   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $346.73 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing a versatile printed circuit board terminal, expertly crafted to hold 4 poles arranged at a right angle This terminal is finished in an elegant pebble grey and features solder pins measuring 45 mm in length Designed with a clamping yoke connection, it is capable of accommodating wire sizes from 15 mm² to a maximum of 25 mm² Each unit is conveniently packaged in a box format, making it an ideal choice for your electronic projects.

Features and Benefits:

    •Compliant with RoHS without exemptions.

    •Meets IEC standards including maximum rated voltage of 1000 V and rated current of 101 A.

    •UL approved with a rating of 600 V and 85 A.

    •Solder pin dimension of 1.2 x 1.2 mm.

Specifications:

 Depth 29.1 mm
 Height 41.5 mm
 Width 58 mm
 Operating temperature, min -50 °C
 Operating temperature, max 120 °C
 Insulating material Wemid (PA)
 Clamping range, min 1.31 mm²
 Clamping range, max 25 mm²
 Rated current (Use group B / UL 1059) 85 A
 Rated voltage (Use group B / UL 1059) 600 V
 Protection degree IP20
 Volume resistance 0.50 mΩ
 Stripping length 16 mm
