2766600000 - 7.62mm Female PCB Connector, 8-Pole, 180° Angle (Pack of 20)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing a reliable PCB plug-in connector, specifically crafted for female plugs with a 762 mm pitch This connector boasts 8 poles and utilizes a 180° connection method alongside a sturdy clamping yoke Meeting UL certification standards, it ensures safety and performance Designed to handle voltages up to 1000 V with an IEC rating, it accommodates wire sizes ranging from 02 mm² to 10 mm² Each unit is conveniently packaged in a box for easy storage and transport.

Features and Benefits:

•Compliant with RoHS without exemption.

•No SVHC above 0.1 wt%.

•IP20 protection degree.

•Maximum plugging cycles of 25.

•UL 94 flammability rating of V-0.

•Developed according to international standards.

•Can connect solid and flexible conductors.

Specifications:
