2588560000 - 30mm x 40mm Lead-Free PVC Cable Duct, 2m Long (Pack of 48)

SKU: SKU: 2588560000 Download PDF

Select a Variant:

2588560000 - 30mm x 40mm Lead-Free PVC Cable Duct, 2m Long (Pack of 48)

SET THE QTY:

Now $293.76 Web pricing policy

~~BEFORE $0.00~~ Now $293.76 Web pricing policy

Sold out

Shipping calculated at checkout.

IN STOCK
Shipping Available

Free shipping on orders above $1000. *Wires and cables only.

View full details

Product Information Resources Reviews

Product Information

Description:

Optimize your cable management with this 2,000 mm long duct, featuring a height of 30 mm and a width of 40 mm Crafted from lead-free PVC, this product adheres to RoHS standards It allows for flexible installation with options for screws or adhesive, and its innovative non-tracking design promotes cleanliness The duct includes a slit gap of 12 mm and a slit width of 8 mm, offering a substantial cross-sectional area of 920 mm² for efficient wire passage.

With a UL 94 flammability rating of V-0, this cable duct is safe to use within a temperature range of -5 to 60 °C, making it a reliable choice for various environments.

Features and Benefits:

•RoHS compliant without exemption.

•Halogen-free material.

•Mounting options available: screws, adhesive, and rivets.

•Non-tracking material.

•Design fits various installations.

Specifications:

Operating temperature range	-5...60 °C
Height	30 mm
Width	40 mm
Length	2,000 mm
Net weight	260 g
Slit gap	12 mm
Slit width	8 mm
UL 94 flammability rating	V-0
Usable cross-section	920 mm²
Basic material	PVC / lead-free
Compliance	{'RoHS compliance status': 'Compliant without exemption', 'REACH SVHC': 'No SVHC above 0.1 wt%'}
Standards	In accordance with DIN EN 50085
Type of mounting	when screwed in, with adhesive, riveted
