2529070000 - 7.62mm Male PCB Connector, 3 Poles, 90° Angle (Pack of 48)

2529070000 - 7.62mm Male PCB Connector, 3 Poles, 90° Angle (Pack of 48)

SKU: SKU: 2529070000   Download PDF

Select a Variant:
  • 2529070000 - 7.62mm Male PCB Connector, 3 Poles, 90° Angle (Pack of 48)
Qty:
Regular price Now $293.69   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $293.69 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing a reliable PCB plug-in connector, designed with a male header that features a closed side and solder connections suitable for through-hole technology (THT) and through-hole reflow (THR) This connector boasts a 762 mm pitch and includes three poles configured at a 90° angle The tin-plated solder pins measure 26 mm in length and are neatly packaged in black Perfect for a variety of electronic applications, this connector combines functionality and ease of use.

Features and Benefits:

    •Compliant with RoHS standards.

    •Approvals include UL File Number E60693.

    •Touch-safe protection according to DIN VDE 57 106.

    •Can be coded for secure connections.

    •Used for board connections in various electronic applications.

Specifications:

 Number of poles 3
 Solder pin length 2.6 mm
 Operating temperature, min. -50 °C
 Operating temperature, max. 130 °C
 Rated current 41 A
 Rated voltage 1,000 V
 Pitch 7.62 mm
 Creepage distance, min. 9.6 mm
 Clearance distance, min. 6.9 mm
 Material PA 9T
 Insulating material group II
 UL 94 flammability rating V-0
