1950960000 - 7.62mm PCB Male Connector with 10 Poles at 180° Angle (Pack of 50)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Presenting a robust male plug-in connector, perfect for PCB applications with a pitch of 762 mm This connector supports 10 poles arranged at a 180° angle, featuring an efficient clamping yoke connection that accommodates a maximum conductor size of 6 mm² Compliant with safety standards such as RoHS and UL, it comes packaged securely in a box, ensuring no exemptions on compliance Its versatile design supports wire sizes from 0.

2 to 10 mm², making it suitable for both solid and flexible conductors across various cross-sectional areas This model boasts an IP20 protection rating, ensuring touch safety as per relevant guidelines.

Features and Benefits:

•Compliant with RoHS regulations.

•Clamping yoke connection method for secure attachment.

•Can accommodate wire cross sections from 0.2 mm² to 6 mm².

•Touch-safe protection ensuring safe use.

•Can be coded for specific applications.

•High insulation resistance and temperature ratings.

•Suitable for PCB assembly and field connections.

•Used in various electrical and electronic systems requiring reliable connectivity.

Specifications:
