1635920000 - 10.16mm PCB Connector with 2 Poles and 3.2mm Solder Pins (Pack of 20)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the LU 1016/02/90 4STI 32SN GY BX connector, designed with precision and reliability in mind This component boasts printed circuit board terminals arranged with a 1016 mm pitch and features two poles The solder pin extends to 32 mm, crafted from a durable pebble grey material It utilizes a clamping yoke for connections, accommodating wire sizes up to a maximum of 16 mm² Meeting rigorous IEC standards for up to 1000 V and 76 A, as well as UL specifications for 300 V and 65 A, this connector promises safety and performance.

It comes in a convenient box and is fully compliant with RoHS regulations, ensuring an environmentally friendly choice.

Features and Benefits:

•Clamping yoke connection for secure termination.

•RoHS compliant without exemption.

•Suitable for various conductor types including fine-wired and stranded.

Specifications:
