1391430000 - Self-Adhesive 24.5x100mm Vinyl Markers for Conductors and Cables

1391430000 - Self-Adhesive 24.5x100mm Vinyl Markers for Conductors and Cables

SKU: SKU: 1391430000   Download PDF

Select a Variant:
  • 1391430000 - Self-Adhesive 24.5x100mm Vinyl Markers for Conductors and Cables
Qty:
Regular price Now $380.16   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $380.16 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing the THM WO VIN 245/100 WS, a reliable solution for marking wires and cables With dimensions of 245 x 100 mm, this product is compatible with conductor diameters ranging from 8 to 23 mm Available in a clean white color, it is made from durable vinyl film and features a strong polyacrylate adhesive for lasting performance Adhering to RoHS regulations without exemptions, this item contains no Substances of Very High Concern (SVHC) above 0.

1 wt% It operates effectively within a temperature range of -40 to 80 degrees Celsius, and its self-adhesive backing ensures excellent adhesion on various surfaces.

Features and Benefits:

    •Produced with a vinyl film base.

    •Self-adhesive for easy application.

    •Compliant with RoHS regulations.

    •Halogen-free.

    •Marking conductors and cables.

Specifications:

 Depth 0.065 mm
 Height 24.5 mm
 Width 100 mm
 Net weight 994 g
 Operating temperature range -40...80 °C
 Adhesive Polyacrylate adhesive
 Basic material Vinyl film
 Conductor cross-section, max 95 mm²
 Conductor cross-section, min 0.75 mm²
 Conductor O.D. 8 - 23 mm
 Cross-section for connected wire 0.75 - 95 mm²
 Number per roll 2000
 Printed characters without
 Size of labelling field 25 x 24.5 mm
 Type of printing neutral
 UL 94 flammability rating V-0
 Text field height 25 mm
 Text field width 24.5 mm
 ECLASS 9.0 27-40-04-01
