Belden 19511 14 AWG 3 Conductor 41x30 Stranding Bare Copper 300V Portable Cordage Cable

Description:-

Portable Cordage, 3 Conductor 14 AWG (41x30) Bare Copper, PVC Insulation, PVC Outer Jacket, UL Type SJTOW.

Insulation:-

• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.033 in (0.84 mm)
• Nom. Insulation Diameter: 0.139 in (3.53 mm)

Outer Jacket:-

• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.040 in (1.0 mm)
• Nom. Diameter: 0.380 in (9.65 mm)
• Overall Cable Diameter (Nominal): 0.380 in (9.65 mm)
• Separator: Paper Tape

Standards:-

• UL Voltage Rating: 300 V (Type SJTOW)
• Operating Temperature Range: -20°C to +105°C

Applications:-

• Portable cordage for supplying power to appliances and tools

Specifications:-

• Size (AWG): 14
• No. of Conductors: 3
• Stranding: 41x30
• Conductor Material: BC - Bare Copper
• Part Number: 19511
