Belden 19509 18 AWG 3 Conductor 42x34 Stranding Bare Copper 300V Portable Cordage Cable

Description:-

Portable Cordage, 3 Conductor 18 AWG (42x34) Bare Copper, PVC Insulation, PVC Outer Jacket, UL Type SJTOW.

Insulation:-

• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.032 in (0.81 mm)
• Nom. Insulation Diameter: 0.110 in (2.79 mm)

Outer Jacket:-

• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.038 in (0.97 mm)
• Nom. Diameter: 0.315 in (8.00 mm)
• Overall Cable Diameter (Nominal): 0.315 in (8.00 mm)
• Separator: Paper Tape

Standards:-

• UL Voltage Rating: 300 V (Type SJTOW)
• Operating Temperature Range: -20°C to +105°C

Applications:-

• Portable cordage for supplying power to appliances and tools

Specifications:-

• Size (AWG): 18
• No. of Conductors: 3
• Stranding: 42x34
• Conductor Material: BC - Bare Copper
• Part Number: 19509
