Belden 19402 18 AWG 3 Conductor 42x34 Stranding Bare Copper Portable Cordage Cable

Description:

Portable Cordage, 3 Conductor 18 AWG (42x34) Bare Copper, PVC Insulation, PVC Outer Jacket, UL Type SVT.

Insulation:

• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.018 in (0.46 mm)
• Nom. Insulation Diameter: 0.084 in (2.1 mm)

Outer Jacket:

• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.034 in (0.86 mm)
• Nom. Diameter: 0.253 in (6.43 mm)
• Overall Cable Diameter (Nominal): 0.253 in (6.43 mm)
• Paper Tape: Separator

Standards:

• Voltage Rating: (Type SVT)
• Operating Temperature: -20°C to +60°C

Applications:

• Portable cordage for supplying power to appliances and tools

Specifications:

• Size (AWG): 18
• No. of Conductor: 3
• Stranding: 42x34
• Conductor Material: BC - Bare Copper
• Part Number: 19402
