Belden 19510 16 AWG 3 Conductor 65x34 Stranding Bare Copper 300V Portable Cordage Cable

Description:

Portable Cordage, 3 Conductor 16 AWG (65x34) Bare Copper, PVC Insulation, PVC Outer Jacket, UL Type SJTOW-A.

Insulation:

• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.033 in (0.84 mm)
• Nom. Insulation Diameter: 0.124 in (3.15 mm)

Outer Jacket:

• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.038 in (0.97 mm)
• Nom. Diameter: 0.34 in (8.6 mm)
• Separator: Paper Tape

Standards:

• Voltage Rating: 300V
• Operating Temperature: -35°C To +105 °C

Applications:

• Portable cordage and cordage

Specifications:

• Size (AWG): 16
• No. of Conductor: 3
• Stranding: 65x34
• Conductor Material: BC - Bare Copper
• Part Number: 19510
